DN50–200 Fully Automatic Tube-Replacement Water Meter Test Bench (Gravimetric Method)

Name: DN50–200 Water Meter Bench – Tube-Replacement Gravimetric | KINMY
SKU: KINMY-KT-7181839

Request Specifications

Tell us the meter size, test method and required testing capacity.

DN50–200 water meter test bench, tube-replacement configuration, gravimetric, fully automatic. Request configuration details from KINMY.

Nominal Diameter: DN50–200
Test Method: Gravimetric Method
Layout: Tube-Replacement
Automation: Fully Automatic

SKU: KINMY-KT-7181839

Category: DN50–200, Water Meter Test Bench Series

Tags: Fully Automatic, Gravimetric Method, Tube-Replacement

Overview

DN50–200 Fully Automatic Tube-Replacement Water Meter Test Bench (Gravimetric Method) is listed in the KINMY Water Meter Test Bench Series range with a configuration identified by DN50–200, Gravimetric Method, Tube-Replacement, Fully Automatic. Contact KINMY for a project-specific specification sheet and quotation.

Configuration

Nominal Diameter	DN50–200
Test Method	Gravimetric Method
Layout	Tube-Replacement
Automation	Fully Automatic

Product Highlights

High production efficiency;
Fast input method: Wireless barcode scanner input for form numbers, fast, accurate, and convenient;
Energy saving, water saving, electricity saving, and labor saving;
Compact size: Saves space, fully automated, shared network, and saves auxiliary materials;
Novel structure: 304 stainless steel piping, novel and elegant appearance.

Reference Specifications

Measurement Uncertainty	Urel≤0.2% (k=2)
Flow Stability	1.0% for Start-Stop Method; 0.2% for Other Methods
Calibration Medium	Pure Tap Water
Operating Humidity	≤ 93% RH
Operating Water Temperature	20℃ ± 10℃
Device Operating Temperature	4˜50℃
Water Source Operating Pressure	0.0-0.5 MPa (Adjustable)
Air Source Operating Pressure	0.4-0.7 MPa
Number of Meters Under Test	DN50: 3 units \| DN65, DN80: 2 units \| DN100, DN150, DN200: 1 unit
Meter Clamping Mechanism	Dual-Cylinder External-Push Tandem Meter Clamping Device; Single Pneumatic Clamping Device for 10 Front 5 Rear Positions
Vacuum System	Differential-Pressure Vacuum Generator, Vacuum Priming, Maintains Water Meters in Full-Water State
Supported Test Modes	Fully Automatic, Semi-Automatic, Touchscreen Manual

Request Specifications

Final configuration, test range and supplied components can vary by project and selected method. Please send your meter sizes, required test method and expected testing capacity for confirmation.
